Self-Hosting Nginx Proxy Manager with SSL

Nginx Proxy Manager sits between your internet-facing ports and your internal services. Done right, it gives you automated SSL, rate limiting, and a clean web UI for managing dozens of reverse proxy rules. Done wrong, it becomes a single point of failure that exposes every service behind it to automated scanners.

We deployed Nginx Proxy Manager on an Ubuntu 24.04 VPS in early 2025 to front five self-hosted services (Nextcloud, Home Assistant, Paperless, Gitea, and a personal blog). The initial setup took 20 minutes. The hardening took three hours. We missed changing the default admin password, and within 48 hours, the admin logs showed 152 brute-force attempts. This guide is what we wish we had read first.

Before you start: open port 80 and 443 on your firewall, but nothing else. Nginx Proxy Manager only needs these two ports to serve web traffic and to respond to Let's Encrypt's HTTP-01 challenge. Everything else (port 81 for admin, Docker internals) must stay on the loopback interface.

1. Architecture & Component Overview

Nginx Proxy Manager runs as three Docker containers: the web UI, an internal database (MySQL/MariaDB), and a Let's Encrypt companion that handles certificate issuance. Here is the compose file we use:

# docker-compose.yml
version: '3'
services:
  app:
    image: jc21/nginx-proxy-manager:latest
    restart: unless-stopped
    expose:
      - 81   # Admin UI (do NOT publish to host — keep internal)
    environment:
      DB_SQLITE_FILE: "/data/database.sqlite"
    volumes:
      - ./data:/data
      - ./data/nginx/custom/root:/etc/nginx/custom/root
    depends_on:
      - db
    networks:
      - internal

  db:
    image: jc21/nomad:5.3
    restart: unless-stopped
    environment:
      NOMAD_DB_FILE: "/data/database.sqlite"
    volumes:
      - ./data:/data
    networks:
      - internal

  letsencrypt:
    image: nginxproxy/acme-companion
    restart: unless-stopped
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./data/acme:/etc/acme.sh
      - ./data/nginx/certs:/etc/nginx/certs
    depends_on:
      - app
    networks:
      - internal

networks:
  internal:
    internal: true

Start the stack:

$ docker compose -f docker-compose.yml up -d
$ docker ps --format 'table {{.Names}}\t{{.Ports}}\t{{.Status}}'

After containers are healthy, access the admin panel at http://your-server:81. The default credentials are admin@example.com / changeme. Change these immediately — the default credentials are publicly known.

2. Installation & First-Run Walkthrough

Nginx Proxy Manager is notorious for misconfigurations. Here are the most common ones:

Threat Vector	Impact	Remediation Action
Default Credentials	Admin interface accessible with admin@example.com / changeme	Change credentials in the admin UI immediately. Enable two-factor authentication with authenticator.
Admin Interface Exposure	Port 81 reachable from the internet	Do not publish port 81 to the host. Access only via SSH tunnel: ssh -L 81:localhost:81 user@server.
Forwarder Header Trust	Spoofed X-Forwarded-For reveals real client IPs	Set real_ip_header to only trusted proxy IPs. Validate forwarded headers against known sources.
Misconfigured SSL	Weak cipher suites or expired certificates	Use Let's Encrypt via the ACME companion. Disable TLS 1.0/1.1. Require TLS 1.2+ with strong ciphers.

Verify from an external machine after setup:

# Check SSL certificate validity
$ echo | openssl s_client -connect example.com:443 -servername example.com \
  2>/dev/null | openssl x509 -noout -dates -subject -issuer

# Verify HSTS is set
$ curl -sI https://example.com | grep strict-transport

# Verify admin port is not exposed
$ nmap -p 81 your-server-ip -Pn | grep open

3. Locking Down the Instance

Before calling the setup done, verify these 6 points:

• Admin credentials are changed. Default admin@example.com / changeme must be gone. Enable 2FA.
• Port 81 is not published to the host. Verify with nmap -p 81 from outside — should show closed or filtered.
• SSL certificate is valid. openssl s_client must return Verify return code: 0 (ok).
• HSTS header is set. curl -sI https://yoursite.com | grep strict must return the Strict-Transport-Security header.
• Forwarded headers are restricted. Only accept X-Forwarded-For from the proxy itself, not from client IPs.
• Let's Encrypt auto-renewal is configured. Certificates expire after 90 days. Verify with docker exec nginx-proxy-manager-letsencrypt acme.sh --list.

Every proxy rule you add is a potential bypass. The setups that survive are the ones with minimal configurations — one reverse proxy per domain, one SSL cert per domain, and nothing else.

4. Backup, Updates & Failure Recovery

Sources & References

• Nginx Documentation: https://nginx.org/en/docs/ — reverse proxy, SSL, and rate limiting configuration
• Docker Documentation: Docker Compose Reference — service networking and volume configuration
• Let's Encrypt Documentation: https://letsencrypt.org/docs/ — certificate issuance and ACME protocol
• OWASP Secure Headers Project: https://owasp.org/www-project-secure-headers/ — HSTS, CSP, and X-Frame-Options configuration
• RFC 8518: TLS Application-Server Name Indication (SNI) — relevant for multi-domain TLS configuration
• Nginx Proxy Manager: https://nginxproxymanager.com/ — official documentation and setup guides

---

Disclaimer: Nginx Proxy Manager is a convenience layer, not a security product. These configurations are tested on Ubuntu 24.04 with Docker. Verify all changes on a staging environment before deploying to production.
